Double XL Liquid Tight

Commercial Environment

Variants:

C/M/F:

VOSB load class 600
Axle Loads: up to 20 tonnes
Forklift (solid tires:) 7.5 tonnes
Forklift (pneumatic tires): 9 tonnes
Point loads: 5 tonnes

Product Enquiry

Name
First Last
Company name
Email
Phone
Address
Street Address Address Line 2 City County / State / Region ZIP / Postal Code Country
Comments

Please click the cloud icon in the bottom left to download your BIM file.

SPECIFICATION
Double XL Liquid Tight | Commercial Environment | 1995x1495x180SKU: KEL-SLA-DXT-002C/M/F: Supplied by Hardscape Products LTD
Size:1995(w) x 1495(l) x 180(d)
Length (mm) X-axis:1495
Width (mm) Y-axis:1995
Depth (mm) Z-axis:180
Weight Per Unit:1298kg
Manufacturing Standard:BS EN 1338:2003
Density:2350 kg/m3
GWP (total) kgCO2e:138.31 kgCO2e/unit
Reference Code:BEDRIJFSMILIEU VLOERPLAAT-199.5x149.5x18
Fitted With:Without lifting tubes, installation via vacuum lifting only. Double mesh non-structural reinforcement.
Edge Style:5x5mm

Double XL Liquid Tight | Commercial Environment | 1995x1495x180

Downloads

Kellen Maintenance Guide

Specification & technical data aligns with our most recent testing, but is indicative and should be treated as such. Some images are computer renders, and all are for illustrative purposes only, exact colours may vary.
